C-Vision Encrypt

What it does

Portable 2-channel Diver Video and Communications System with File Encryption Software

Image Gallery

Information

The system allows both video and voice communications to be monitored and recorded in one rugged, easy to operate unit. In comparison to the standard C-Vision system, the Encrypt model offers 4 wire (round robin) mode communications, as well as boasting robust Mil. Spec umbilical connectors, direct interface connections and high level file encryption software for the protection of sensitive data.

This product is NATO approved and is identified with NATO Stock Number (NSN) 5895–99–844-9420.

Technical Detail

Code: CV2/M/ENC
Description: C-Vision Encrypt Surface Control Unit

Technical specification

  • Dimensions: 489 x 390 x 185mm
  • Weight: 13 Kgs
  • IP rating: 67 (closed), 65 (open)
  • Input Power:  96-264 VAC
  • Power Consumption:  600W Max.
  • Internal Storage: 500GB SSD
  • Operating System: PC Windows 10
  • CPU: Intel Core i7-7700 3.6GHz
  • Memory: 8GB DDR4 2133MHz
  • Keyboard: 84-key UK QWERTY
  • Display (on-board): 15.6” LCD Panel
  • Display (external): HDMI
  • Video Channels: 2 – video and snapshot
  • Overlay: Time/Date/Timer/Logo
  • Communications Channels: 3, duplex
  • Encryption Standard: AES-256 (256 bit encryption)
  • Battery Backup: 12V 6Ah for comms system
  • Umbilical Inputs: 12-pin Souriau UTS
  • Other Interface: 2x USB-A, 1x ethernet
  • NATO approved - NSN no. 5895–99–844-9420
  • Supplied with: Premium operator headset, accessory cable set, encryption key

Applications

  • Military Diving
  • Police Diving
